TYPE
Vapor Clean: a simple cleaning function using steam to loosen deposits in the oven cavity. Induction: The work of these hobs is based on the principle of electromagnetic induction. The heat is generated directly in the bottom of the pan during its contact with the hob.
Product Family: Cooker
Cooker size: 100x60 cm
Hob energy type: Electric
N. of ovens: 3
Hob type: Induction
Main oven type: Thermo-ventilated
Type of second oven: Thermo-ventilated
Cleaning system: Vapor Clean
AESTHETICS
Colour: Black
Finishing: Gloss Black
Aesthetics: Victoria
Design: Victoria
Material: Enamelled
Door: With frame
Command panel finish: Enamelled metal
Hob colour: Black enamel
Handle: Smeg Victoria
Controls colour: Stainless steel
Upstand: Yes
Display: electronic 5 buttons
Glass type: Black
Handle Colour: Brushed stainless steel
Control knobs: Smeg Victoria
No. of controls: 9
Plinth: Anthracite
PROGRAMS / FUNCTIONS
Traditional cooking functions
Upper and lower element only: a traditional cooking method best suited for single items located in the centre of the oven. the top pf the oven will always be hottest. Ideal for roast, fruit cakes, bread etc.Static Fan with upper and lower elements: The elements combined with the fan aim to provide more uniform heat, a similar method to conventional cooking, so pre-heat is required. Most suitable for items requiring slow cooking methods.Fan assisted Circulaire: The combination of the fan and circular element around it gives a hot air cooking method. This provides many benefits including no preheat if cook time is more than 20 minutes, no flavour transfer when cooking different foods at the same time, less energy, and shorter cook times. Good for all types of food.Circulaire ECO: The combination of the grill, fan and lower element is particularly suitable for cooking small quantities of food.ECO Circogas: In gas ovens the fan distributes the heat quickly and evenly throughout the oven cavity, avoiding flavour transfer when cooking a number of different dishes at the same time. In electric ovens this combination completes cooking more quickly of foods that are ready on the surface, but that require more cooking inside, without further browning.Fan assisted base
Cleaning functions
Vapor Clean: a simple cleaning function using steam to loosen deposits in the oven cavity.Vapor Clean
Other functions
Defrost by time: with this function the time of thawing of foods are determined automatically.Defrost by time
PROGRAMS / FUNCTIONS AUXILIARY OVEN
Cooking functions cavity 2: 1
Traditional cooking functions, cavity 2
Circulaire: The combination of the fan and circular element around it gives a hot air cooking method. This provides many benefits including no preheat if cook time is more than 20 minutes, no flavour transfer when cooking different foods at the same time, less energy, and shorter cook times. Good for all types of food.Circulaire
PROGRAMME / FUNCTIONS THIRD OVEN
No. of functions third oven: 1
HOB OPTIONS
Child lock: some models are fitted with a device to lock the programme/cycle so it cannot be accidentally changed. ECO-logic: option allows you to restrict the power limit of the appliance real energy saving.
Control Lock / Child Safety: Yes
Limited Power Consumption Mode: Yes
Limited Power Consumption Mode in W: 3700, 4800, 7400 W
OPTIONS MAIN OVEN
Timer: Yes
End of cooking acoustic alarm: Yes
Minimum Temperature: 50 °C
Maximum temperature: 250 °C
OPTIONS AUXILIARY OVEN
Minimum Temperature: 50 °C
Maximum temperature: 245 °C
OPTIONS THIRD OVEN
Minimum Temperature: 50 °C
Maximum temperature: 260 °C
HOB TECHNICAL FEATURES
Total no. of cook zones: 5
1st zone position: Front left
2nd zone position: Rear left
3rd zone position: Central
4th zone position: Rear right
5th zone position: Front right
1st zone type: Induction - single
2nd zone type: Induction - single
3rd zone type: Induction - single
4th zone type: Induction - single
5th zone type: Induction - single
1st zone dimensions: - Ø 21.0 cm
2nd zone dimensions: - Ø 18.0 cm
3rd zone dimensions: - Ø 27.0 cm
4th zone dimensions: - Ø 18.0 cm
5th zone dimensions: - Ø 21.0 cm
1st zone power: 1.30 kW
2nd zone power: 2.30 kW
3rd zone power: 2.30 kW
4th zone power: 1.30 kW
5th zone power: 2.30 kW
1st zone booster power: 1.40 kW
2nd zone booster power: 3.00 kW
3rd zone booster power: 3.00 kW
4th zone booster power: 1.40 kW
5th zone booster power: 3.00 kW
MAIN OVEN TECHNICAL FEATURES
All glass inner door: All glass inner door, a single flat surface which is simple to keep clean. Air cooling system: to ensure a safe surface temperatures. Triple glazed doors: Number of glazed doors. The capacity indicates the amount of usable space in the oven cavity in litres. Enamel interior: The enamel interior of all Smeg ovens have a special antacid lining which helps keep the interior clean by reducing the amount of cooking grease adhering to it. The oven cavity has 4 different cooking levels. Tilting grill: the tilting grill can be easily unhooked to move the heating element and clean the roof of the appliance in one simple step. Side lights: Two opposing side lights increase visibility inside the oven.
Net volume of the cavity: 61 litres
Gross volume, 1st cavity: 70 l
Cavity material: Easy clean enamel
Shelf positions: 4
Type of shelves: Metal racks
No. of lights: 1
Light type: Halogen
Light power: 40 W
Fan number: 1
Cooking time setting: Start and Stop
Door opening: Side opening
Side opening door: Yes
Removable door: Yes
Full glass inner door: Yes
Total no. of door glasses: 3
No.of thermo-reflective door glasses: 1
Safety Thermostat: Yes
Cooling system: Tangential
Grill type: Electric
Tilting grill: Yes
Grill elememt: 1700 W
Large grill - Power: 2700 W
Lower heating element power: 1200 W
Upper heating element - Power: 1000 W
Circular heating element - Power: 2000 W
Temperature control: Electro-mechanical
SECOND OVEN TECHNICAL FEATURES
Enamel interior: The enamel interior of all Smeg ovens have a special antacid lining which helps keep the interior clean by reducing the amount of cooking grease adhering to it. The oven cavity has 9 different cooking levels. All glass inner door: All glass inner door, a single flat surface which is simple to keep clean. Air cooling system: to ensure a safe surface temperatures. The capacity indicates the amount of usable space in the oven cavity in litres. Double glazed doors: Number of glazed doors. Side lights: Two opposing side lights increase visibility inside the oven. Electronic control: Allows you to maintain temperature inside the oven with the precision 2-3 ° C. This enables to cook meals that are very sensitive to temperature changes, such as cakes, souffles, puddings.
Net volume of the second cavity: 84 litres
Cavity material: Easy clean enamel
Shelf positions: 9
Type of shelves: Metal racks
No. of lights: 1
Light type: Halogen
Light power: 40 W
Fan number: 2
Door opening: Side opening
Side opening door: Yes
Removable door: Yes
Full glass inner door: Yes
Removable inner door: Yes
No. total door glasses: 2
No. thermo-reflective door glasses: 1
Safety Thermostat: Yes
Cooling system: Tangential
Temperature control: Electro-mechanical
THIRD OVEN TECHNICAL FEATURES
Enamel interior: The enamel interior of all Smeg ovens have a special antacid lining which helps keep the interior clean by reducing the amount of cooking grease adhering to it. The oven cavity has 2 different cooking levels. Side lights: Two opposing side lights increase visibility inside the oven. All glass inner door: All glass inner door, a single flat surface which is simple to keep clean. The capacity indicates the amount of usable space in the oven cavity in litres. Air cooling system: to ensure a safe surface temperatures. Triple glazed doors: Number of glazed doors. Tilting grill: the tilting grill can be easily unhooked to move the heating element and clean the roof of the appliance in one simple step.
Net volume, 3rd cavity: 36 l
Gross volume, 3rd cavity: 41 l
Cavity material: Easy clean enamel
Shelf positions: 2
Type of shelves: Metal racks
No. of lights: 1
Light type: Halogen
Light power: 40 W
Door opening: Flap down
Removable door: Yes
Full glass inner door: Yes
Removable inner door: Yes
No. total door glasses: 3
No. of thermo-reflective door glasses: 1
Safety Thermostat: Yes
Cooling system: Tangential
Grill type: Electric
Tilting grill: Yes
Large grill - Power: 2700 W
Temperature control: Electro-mechanical
PERFORMANCE / ENERGY LABEL
A: Product drying performance, measured from A+++ to D / G depending on the product family
Energy efficiency class: A
GAS - Energy consumption in fan-forced convection, first cavity: 2.77 MJ
Energy consumption forced air convection (kWh) first cavity: 0.77 KWh
GAS - Energy consumption conventional mode, first cavity: 4.07 MJ
Energy consumption conventional first cavity (kWh): 1.13 KWh
Energy consumption for the hob: 191.4 Wh/Kg
Energy consumption zone 1: 199 Wh/Kg
Energy consumption zone 2: 191 Wh/Kg
Energy consumption zone 3: 195 Wh/Kg
Energy consumption zone 4: 190 Wh/Kg
Energy consumption zone 5: 182 Wh/Kg
PERFORMANCE /ENERGY LABEL - SECOND CAVITY
B: Product energy rating, measured from A+++ to D / G depending on the product family.
Energy efficiency class, second cavity: B
GAS - Energy consumption in forced air convection, second cavity: 3.89 MJ
GAS - Energy consumption in forced air convection, second cavity: 1.08 KWh
ELECTRICAL CONNECTION
Nominal power: 15400 W
Voltage: 220-240 V
Voltage 2 (V): 380-415 V
Frequency: 50/60 Hz
Type of electric cable: Yes, Double and Three Phase
Power supply cable length: 150 cm
Type of electric cable installed: Yes, Single phase
LOGISTIC INFORMATION
Dimensions of the product HxWxD (mm): 900x1000x600 mm
Width (mm): 1000 mm
Product Height (mm): 900 mm
Depth (mm): 600 mm
Dimensions of the packed product (mm): 1015X1060X670 mm
Gross weight (kg): 129.100 kg
Net weight (kg): 117.400 kg
FR EXTENTION SINGLE GROUP
Packed width: 1060 mm
Packaged depth: 670 mm
Height (mm) packed: 1015 mm
Maximum stackability: 4
Type of packaging: Cardboard
Packaging composition - paper & cardboard (kg): 6.066 kg
Packaging composition - polystyrene (kg): 1.890 kg
Packaging composition - wood (kg): 3.360 kg
Packaging composition - plastic (kg): 0.357 kg
